Varmint Guard III - Setup & Use

Not sure if this is your device? This article is for the Varmint Guard III (SKU/Product #: MFA-15134). Double-check this info or visit our "Identify My Device" page before you continue.

The Varmint Guard III is a heavy-duty metal cage designed to protect compatible trail cameras from damage caused by bears, raccoons, and other wildlife. It mounts to a tree using straps and provides a physical barrier around the camera while allowing full functionality.



What's In The Box

  • Varmint Guard III cage
  • Mounting straps
  • Mounting hardware

Compatible Cameras

The Varmint Guard III is compatible with select Moultrie trail cameras. Refer to the product packaging or the Moultrie website to confirm compatibility with your specific camera model before purchasing.

How To Set Up

  1. Select a suitable tree or post at your desired camera location.
  2. Position your trail camera at the desired mounting height, typically 3–5 feet off the ground and angled slightly downward toward the target area.
  3. Mount your trail camera to the tree using its standard strap or mounting arm.
  4. Open the front door of the Varmint Guard III cage.
  5. Place the Varmint Guard III cage around the mounted camera.
  6. Align the cage so the camera lens lines up with the opening in the front of the cage.
  7. Ensure the camera PIR sensor (motion detector) is not obstructed by the cage.
  8. Secure the Varmint Guard III cage to the tree using the included mounting straps.
  9. Tighten the straps firmly to prevent the cage from shifting or rotating.
  10. Close and latch the front door of the cage.
  11. Power on the camera and verify normal operation through the Moultrie Mobile app.

Usage Tips

  • Inspect the cage periodically for damage or corrosion, especially after prolonged field use.
  • Ensure the camera lens and PIR sensor remain unobstructed inside the cage for best detection and image quality.
  • When removing the camera for maintenance, loosen the cage straps before attempting to open the cage door.
